Specifications

Top Cover:
Ductile iron casting, high in strength and ductility has a 1″ (25.4 mm) diameter handle designed into the cover for easy handling and carrying. O-Ring sealed.

Body:
Ductile iron casting, with excellent wear resistant characteristics. The air inlet is cast into the body and tapped with 3⁄4” NPT female threaded ports, along with 1″ (25.4 mm) diameter ergonomically designed side handles for easy handling and carrying. Chuck bolts pass thru the lower body flange into tapped holes in the chuck mounting plate allowing special chucks to be made in a wide variety of shapes and sizes.

Piston:
3-1⁄2” – Alloy steel heat treated with a ground surface with hard chrome plate. Designed with 2 round valve ports to give better lubrication and load distribution to the valve ring while running.

Master Chuck:
The 3 7⁄8” (98.4 mm) I.D. master chuck is of an all welded, reinforced steel and tubing construction. The chuck is equipped with extra long chuck adapter attachment lugs.

Fasteners:
S.A.E.Grade 5 bolts with belleville lock washers. All fasteners are plated.

Throttle Valve:
Each unit includes a Rhino Stainless Steel Throttle Valve. The valve is equipped with a lever lock for safety.

Chuck Adapters:
Standard chuck adapters are available in the following sizes: 1″ (25.4 mm) I.D., 1 1⁄2” (38.1 mm) I.D., 2″ (50.8 mm) I.D., 2 1⁄2” ( 63.5 mm) I.D., 3″ (76.2 mm) I.D., 3 1⁄2” (88.9 mm) I.D. and three channel post chuck adapters for 1.2 to 1.5 lbs/ft, 2 to 2.75 lbs/ft and 3 to 4 lbs/ft posts.

Air Consumption:
42 CFM (1.19 m3/min) @ 90 PSI (6.4 kg/cm2).

Weight:
55lbs.

Height:
21”
