34′ Towable Articulating Boom Lift – TMZ-34/19
Call for Pricing
Add these items to your order
-
Pad For Outriggers
$28.00 / Day
Description
The Genie TMZ34/19 trailer mounted boom is an innovative aerial machine that combines incredible height with convenience. With a heavy-duty frame able to handle the toughest jobs, but lightweight enough to use on grass comfortably, the TMZ34/19 is useable for homeowners as well as contractors. Call us today to reserve this lift for pickup, and finish your vertical jobs with ease.
**THIS UNIT REQUIRES AN UP TO DATE CERTIFICATE OF INSURANCE. UNIT IS ONLY AVAILABLE ON MAUI & BIG ISLAND.
Features
Working Height: 40 ft.
Platform Height: 34 ft.
Height – Stowed: 77.5 in.
Length – Stowed: 19 ft, 9 in.
Width: 59.5 in.
Ground Clearance: 9.5 in.
Platform Length: 32 in.
Platform Width: 48 in.
Platform Railing Height: 44 in.
Toeboard Height: 7 in.
Toeboard Height – Entry: 4 in.
Entry Height: 18 in.
Horizontal Reach – from Pivot: 19 ft.
Horizontal Reach – from Edge of Outrigger Footpads: 14 ft.
Outrigger Footprint – Length: 11 ft.
Outrigger Footprint – Width: 10 ft.
Leveling Capability – Manual Outriggers: 12°
*Hydraulic Outriggers: 10°
Lift Capacity – Standard Platform: 500 lbs.
Turntable Rotation: 359° non-continuous
Towing Speed Rating: 60 mph
Machine Weight: 3185 lbs. (3110 lbs. with hydraulic outriggers)
